Ferrite Core/Arc Permanent Magnet for bldc ceiling fan

FOB Reference Price:Get Latest Price
US $0.01-5 / Piece | 1000 Piece/Pieces (Min. Order)
Supply Ability:
100000 Piece/Pieces per Day
Port:
shenzhen
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
Topmag/OEM
Model Number:
Y8T, T25, Y27H, Y28 etc
Type:
Permanent
Composite:
Ferrite Magnet
Shape:
Ferrite Core/Arc Permanent Magnet for bldc ceiling fan
Application:
Moto Magnet
Product Name:
Ferrite Core/Arc Permanent Magnet for bldc ceiling fan
Magnet Shape:
Rectangular, Cylinder, Disc, Ring or as request
Magnet Size:
As request
Magnet Coating:
Epoxy or as request.
Magnetic Specific:
As request
Magnet Material:
Ferrite Permanent Magnet
Magnet Tolerance:
+/-0.05 to +/-0.01mm
Magnet Color:
Black
Magnet Grade:
Y8T, T25, Y27H, Y28 etc
Delivery time:
Ferrite Core Magnet will be sent out within 25 days
Packaging & Delivery
Packaging Details
Ferrite Core/Arc Permanent Magnet for bldc ceiling fan will be sent with standard sea or air package well protect in the delivery
Delivery Time
within 25 days
Product Description

Ferrite Core/Arc Permanent Magnet for bldc ceiling fan.

Shapes
Cube, cylinder, Block, Bar, Ring, Arc, etc. Over 300 Existing moulds in stock, as your requests.
Certification
ISO9001 : 2008, SGS
Application
a). Motors (e.g. washing machines, drills, food mixers, vacuum cleaners, hand dryers)

b). Generators (e.g. Wind turbines, Wave Power, Turbo Generators, etc)

c). Sensors f). Healthcare

d). Magnetic Separators g). Starter motors

e). Security Systems h). Loudspeaker
Magnet property
Grade
Remanence induction
Br
Coercive force
Hcb
Intrinsic Coercive
force
Hcj
maximum Energy
product
(BH)max
T
KGs
KA/m
KOe
KA/m
KOe
KJ/m³
MGOe
Y8T
200~235
2.0~2.35
125-160
1.57-2.01
210-280
2.64-3.51
6.5-9.5
0.8-1.2
Y25
360~400
3.60~4.00
135-170
1.70-2.14
140-200
1.76-2.51
22.5-28.0
2.8-3.5
Y27H
350~380
3.50~3.80
225-240
2.83-3.01
235-260
2.95-3.27
25.0-29.0
3.1-3.6
Y28
370~400
3.70~4.00
175-210
2.20-3.64
180-220
2.26-2.76
26.0-30.0
3.3-3.8
Y28H-1
380~400
3.80~4.00
240-260
3.01-3.27
250-280
3.14-3.52
27.0-30.0
3.4-3.8
Y28H-2
360~380
3.60~3.80
271-295
3.40-3.70
382-405
4.80-5.08
26.0-30.0
3.3-3.8
Y30H-1
380~400
3.80~4.00
230-275
2.89-3.46
235-290
2.95-3.64
27.0-32.5
3.4-4.1
Y30H-2
395~415
3.95~4.15
275-300
3.45-3.77
310-335
3.89-4.20
27.0-32.0
3.4-4.0
Y32
400~420
4.00~4.20
160-190
2.01-2.39
165-195
2.07-2.45
30.0-33.5
3.8-4.2
Y32H-1
400~420
4.00~4.20
190-230
2.39-2.89
230-250
2.89-3.14
31.5-35.0
3.9-4.4
Y32H-2
400~440
4.00~4.40
224-240
2.81-3.01
230-250
2.89-3.14
31.0-34.0
3.9-4.3
Y33
410~430
4.10~4.30
220-250
2.76-3.14
225-255
2.83-3.20
31.5-35.0
3.9-4.4
Y33H
410~430
4.10~4.30
250-270
3.14-3.39
250-275
3.14-3.45
31.5-35.0
3.9-4.4
Y34
420~440
4.20~4.40
200-230
2.51-2.89
205-235
2.57-2.95
32.5-36.0
4.1-4.4
Y35
430~450
4.30~4.50
215-239
2.70-3.00
217-241
2.73-3.03
33.1-38.2
4.1-4.8
Y36
430~450
4.30~4.50
247-271
3.10-3.40
250-274
3.14-3.44
35.1-38.3
4.4-4.8
Y38
440~460
4.40~4.60
285-305
3.58-3.83
294-310
3.69-3.89
36.6-40.6
4.6-5.1
Y40
440~460
4.40~4.60
330-354
4.15-4.45
340-360
4.27-4.52
37.6-41.8
4.7-5.2
Detailed Images
Packing & Delivery
Our Company

Shenzhen Topmag Technology Co.,Ltd.

As a high-tech enterprise, Top Magnetics Co., Ltd. specializes in the production of earth magnetic materials, tools and components. We provide the high-end level products to our customers by professional operation & management, advanced production equipment & facilities, and strict Q&A process. Our products have been exported to the major market all over the world, Including America, Germany, Portland, India and etc.

1. Shenzhen TopMag Technology CO.,Ltd. which factory is one of the largest manufacturer from Maanshan, Anhui, China, has been exporting ferrite segments and NdFeB for 10 years with good quality and factory price, already passed ISO9001 and TS16949.

2. Our factory specialized in reseraching, developing, producing and marketing of magnets, located in Ma's anshan city, where is only 40 minutes's drive away from Nanjing.

The flexibility of our organization and management, high efficiency of cost control and advanced standard of quality assurance, have earned us strong partnership with several high-tech enterprises, with whom we work together in magnets research and application.

3. Our ferrite segments have reached the performance of FB6, FB9 series of TDK in Japan, can meet different requirements of high Br, high Hcb or both. We also custom manufacture

materials for OEM companies.

4. The most important thing is that our engineer have been focused on magnet field over 20 years, the strategic technical support and positive suggestion can be offered by our professional team.

5. We always insist that "quality first, service first", please be welcomed to vist our office or our factory for guidance and business negotiation.

Our workshop.

Our team.


Our factory.


Our certification

Magnet Application


FAQ

Q: Are you an manufacturer or trading company?

A: We are an manufacturer, TopMag Shenzhen office which is one of the largest manufacturer from Maanshan, Anhui Province, China, has been exporting ferrite segments and NdFeB for 10 years with good quality and factory price, already passed ISO9001 and TS16949.

Q: Where is your factory, how can i vist your company?

A: Our factory located in Maanshan, Anhui Province, China. Welcome to visit our office or factory, but please let us know about the change of your class schedule at least a week earlier, so that we can make the best arrangement for you.

Q: How long is your delivery time?

A: Shipped within 7 days if have exsiting moulds.
Shipped within 3 weeks after received deposit if make moulds according to your drawing.
The finish time of moulds must be controlled within 25 days.

Q: Do you provide free sample?

A: Yes, free sample is available, but the freight to be collected at desitination. This is our company's principle, hope get your understanding.

Q: How do you ensure the quality?

A: Quality is our life, we always attach great importance to the quality controlling from the beginning to the end . We have QC department and strict management system such as ISO9001,TS16949 , CE, ROSH.

Q: What is your terms of payment ?

A: T/T, Western Union, MoneyGram, Paypal available. Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance , balance before shippment..
